Highlight:
1. DVB-S/S2/S2X,DVB+T/T2/ISDB-T/Cable(J83.A/C)/ATSC-C(J83.B)
2. 4K ultra-high definition display and decoder, Dual-core MIPS74Kf processors
3. Multi-Room, Multi-stream, T2-MI, Ca Card
4. Multi-format ultra-high definition video decoder
5. Full PowerVu, DRE &Biss key
6. DLNA, SAT To IP
7. Built-in 2.4G WIFI module, Ethernet
8. Web TV, Xtream, Youtube
9. Regional weather
10. Technical support website: www.freesat.cn
Note: We reserve the right to change the design and OEM/ODM supported
Hardware specifications:
Multi-core CPU architecture:
MIPS 74Kf core operating frequency up to 1GHz,
16KB I-cache, 16KB D-cache and 1 Register File
Demodulation: M1502+Tuner M3031
CPU: Ali M2662 (System:ATS)
Flash: 64MB SPI
DDR3: 4Gb RAM (128M*16*2 )
Packing:
1* V8 UHD Satellite Receiver
1* Adapter
1* IR Remote Control
1* HDMI Cable
1* User Manual
Hardware specifications:
Video Decode: MPEG-2 ISO/IEC 13818-2 MP@ML, ISO/IEC 14496-2 (MPEG4) compliant, Supports SP@L3 to ASP@L5, Multi-format ultra-high definition video decoder (MPEG1/2/4, H.264/265, VC-1, AVS/AVS+, VP8 and VP9)
Video Resolution: By Source, 480i, 480P, 576i, 576P, 720P_50, 720P_60, 1080i_25, 1080i_30, 1080P_25, 1080P_24, 1080P_30, 1080P_50, 1080P_60, 4K2K_25, 4K2K_30, 4K2K_50,4K2K_60
Video DAC: 1 x 10bit DAC for CVBS output,Composite NTSC M/N/J, NTSC-4.43,Composite PAL M/N/B/D/G/H/I, PAL-60
Aspect Mode: Auto, 16:9 Pillar box, 4:3 Pan & Scan, 4:3 Letter Box
HDMI Video Out: Auto, RGB-Normal, RGB-Expand, YCbCr 4:4:4, YCbCr 4:2:2
HDMI deep color: Auto, Normal, None, HDMI deepcolor 24, HDMI deepcolor 36
Panel display: 8-digit white LED display, With multiple function indicators
LED Indicator: Power ON: Green; Standby: Red
Wifi: Built in 2.4G WiFi Support IEEE 802.1.1b/g/n
IR: Exit IR for 38KHz, Infra Remote control
Software Features:
1. Fully comply with DVB-S/S2/S2X (SCPC and MCPC receivable from C/Ku band satellite), DVB T/T2/Cable(J83.A/B/C)/ISDBT, MPEG-2/4 H.265 Standard
2. Automatic network search for newly added transponders, and Supports NIT Search for DVB-T/Cable
3. 6000+ channels TV and Radio programmable
4. Channel Play Type Can choose All, Free and Scrambled
5. You can switch to any other channel while recording the channel, Various channel editing unction(favorite,move,lock,skip,delete,rename,find,sort)
6. 32 different favorite groups selection
7. OSD Language English, French, German, Italian, Spanish, Portuguese, Russian, Turkish, Polish, Arabic, Persian, Thai, Vietnam, Czech, Armenian, Georgian, Ukrainian, Albanian, Hungary, Malay, Indonesisch, Dansk, Greek, Serbian
8. 32-bits OSD Color with anti-flickering
9. OSD Timeout and Transparency, Subtitle Display, Channel list displays pages 1-3. Support menu in the small window to play programs
10. Sets up multiple habitual operation Settings
11. Parental control for channels
12. Plug and Play installation, with an easy to use Menu System
13. Fully support to 7 days Electronic Program Guide(EPG)
14. 8 event timers, off/Once/Daily Mode
